VANTAGE CONTROLS
Vantage InFusion Main Enclosure Terminal Board, 36V
VC-VSUB215
In stock
The VSUB215 is the InFusion Main Enclosure Terminal Board in the 36-volt version, fitted with the reinforced four-screw high-voltage connector. The InFusion Controller plugs into this terminal board within the Main Power Enclosure after all connections have been made. It provides RS-232 and RS-485 ports, controller-bus, station-bus and secondary-enclosure connections.
| Type | InFusion Main Enclosure Terminal Board (36V) |
| High-Voltage Connector | Reinforced 4-screw connector |
| RS-232 Ports | Five (Ports 1-5) |
| RS-485 Ports | Two |
| Auxiliary Power | 12VDC connection, total power limited to 250mA |
| Warranty | 5-year limited (Vantage) |
