VANTAGE CONTROLS
Single Line DALI Power Supply
VC-PSU-DALI
In stock
The Single Line DALI Power Supply is a certified DALI-2 compliant power supply for a single line of the Digital Addressable Lighting Interface (DALI) protocol. Each DALI line in an installation requires a dedicated power supply for correct operation, and this DIN-rail-mounted unit powers one line that may contain lighting fixtures, sensors, switches and interface devices. Indicators display the status of the mains supply connection and the DALI line.
| Order Code | PSU-DALI |
| Nominal Input Voltage | 100 – 240 V ac |
| Input Power | 10 VA |
| Frequency | 50 – 60 Hz |
| DALI Line Capacity | 1 |
| DALI Line Supply Voltage | 18 V dc (nominal) |
| DALI Line Supply Current | 225 mA (guaranteed) / 238 mA (nominal) / 250 mA (maximum) |
| Suitability | DALI and DALI-2 Systems |
| Isolation | > 3.75 kV ac (DALI line/mains supply) |
| Start-up Time | < 20 ms |
| DALI Line Terminals | Screwed – 3 x 1.5 mm² solid/stranded |
| Mains Supply Terminal | Screwed – 3 x 1.5 mm² or 2 x 2.5 mm² solid/stranded per tunnel |
| Ingress Protection | IP20 |
| Materials: Enclosure/Fascia | Flame retardant Polycarbonate, UL 94V-0 |
| Materials: DIN Rail Clip | ABS |
| Weight | 104g |
| Ambient Operating Temp. | 0 to 50° C |
| Ambient Storage Temp. | -10 to 70° C |
| Humidity | 0% to 95% RH non condensing |
| Warranty | 5-year limited (Vantage) |
