PULSE EIGHT
Pulse-Eight ProAudio 16 RS DSP Audio Matrix Kit (48×16, Remote Source)
P8-PRO16-RS KIT
RRP
$8,999.00
incl GST
Backorder
The ProAudio 16 RS is a 16-zone DSP pre-amp audio matrix with Remote Source inputs — 8 of its 48 inputs accept audio extended over Cat5e/6, letting you place sources away from the rack. It distributes to 16 independent zones, each with 5-band EQ, independent volume and gain, subwoofer crossover control and up to 170ms of lip-sync delay, configured from the web interface or through Control4, Crestron, ELAN, RTI and Savant drivers. Supplied as a kit with the required remote-source modules.
| Configuration | 48 audio inputs → 16 output zones (kit) |
| Inputs | 16 × stereo L/R, 16 × digital coax, 8 × optical, 8 × Cat5e remote-source |
| Outputs | 16 × stereo L/R + 16 × digital coax |
| Per-zone DSP | 5-band EQ, volume -20 to +20dB (0.5dB), treble ±20dB, input/output gain -24 to +24dB |
| Subwoofer control | Crossover 50-300Hz, 12/24dB per octave, Butterworth or Linkwitz-Riley, selectable polarity |
| Lip-sync delay | Up to 170ms per zone |
| Supported formats | PCM, Dolby Digital 5.1, DTS |
| Audio performance | 5Hz-20kHz ±0.1dB, S/N >85dB, input impedance 10kΩ |
| Control | RS-232, TCP/IP; Control4, Crestron, ELAN, RTI, Savant drivers |
| Power | IEC C14, 110-240V 50/60Hz |
| Build | Anodised brushed aluminium; rack-mountable; made in Great Britain |
| Safety & emissions | UKCA, CE, FCC, RoHS |
