PULSE EIGHT
Pulse-Eight neo:X 8×10 HDBaseT Matrix Kit (incl. 8 Ultra Receivers)
P8-HDBT2UFFMJ1210-KT
RRP
$25,999.00
incl GST
Backorder
The complete Pulse-Eight neo:X 8×10 HDBaseT matrix solution — the matrix chassis plus eight neo:Ultra Power-over-HDBaseT receivers, ready to deploy out of the box. Route 8 HDMI sources to 8 HDBaseT zones (Class C + DSC) plus 2 mirrored HDMI outputs, carrying HDR and 4K/60 4:4:4 up to 100 m over a single category cable, with the receivers powered down the same cable (PoH).
Full control comes built in: web interface, libCEC, bi-directional IR, set-top-box IP control, Alexa voice control and free remote monitoring, plus a full audio matrix with ARC and audio breakout.
Kit includes the 3U chassis, 8× neo:Ultra PoH receivers, power supply, rack ears, 8× IR blaster cable packs, an 8-button context-sensitive IR remote and installation guide. Built in Britain; three-year warranty.
| Configuration | 8 × HDMI in → 8 × HDBaseT Class C+DSC out + 2 × mirrored HDMI out; audio matrix |
| Distance | 4K up to 100 m (Cat6) / 70 m (Cat5e); 1080p up to 150 m |
| Bandwidth | 18 Gbps (600 MHz) |
| Video | All 4K up to 4:4:4@60Hz, 4:2:2 60Hz HDR10, 1080p (+3D) |
| HDCP | HDCP 1.4 & 2.2 |
| Compression | DSC (Display Stream Compression) |
| Audio | Full audio matrix, ARC, audio breakout; all HDMI formats incl. Dolby Atmos, DTS-HD Master |
| Control | Web interface, libCEC, bi-directional IR, set-top-box IP control, Alexa, remote monitoring |
| Power | IEC C14, 100-240V; PoH to all 8 receivers |
| Dimensions | Matrix 440 × 132 × 316 mm (3U); 4.83 kg |
| In the box | neo:X chassis, 8× neo:Ultra PoH receivers, power supply, rack ears, 8× IR packs, 8-button remote, install guide |
| Certifications | CE, FCC, RoHS; built in Britain |
No compatibility information available for this product.
